Rotary jet heads
Improve process efficiency, productivity and end-product quality with exceptional cleanability of your process tanks. Alfa Laval rotary jet head tank cleaning machines prevent the risk of contamination across dairy, food, beverage, pharmaceutical and industrial applications. Choose between two series of tank cleaning machines: hygienic process models and industrial process models.
Thoroughly clean tanks boost productivity and product quality
- Robust design
- Save time, water and cleaning media
- Enhance safe working conditions using automated cleaning with no man-entry required
- Safeguard process integrity and product quality with proven cleaning validation for hygienic processes
Ensure process and product safety with 100% clean tanks. Alfa Laval rotary jet heads deliver faster cleaning times and sustainable savings from reduced water and cleaning media consumption.
Choose from a broad rotary jet head portfolio for cleaning tank capacities from 200 litres up to 500,000 litres and beyond. Then customize these tank cleaning machines with options to meet your exact tank cleaning requirements.
These self-cleaning, self-draining rotary jet heads meet the rigorous demands for tank cleaning in hygienic and sterile processes.
- Suitable for tank cleaning duties in dairy, food, beverage, biotech and pharmaceutical industries
- Alfa Laval Q-doc documentation, including EN 10204 (MTR) 3.1.B, FAT and SAT, and ATEX certificates
- Compliance with current Good Manufacturing Practices (cGMP) for Alfa Laval UltraPure portfolio for sterile processes
Cleaning industrial process tanks calls for a rugged, reliable and effective tank cleaning machine that can handle harsh operating environment and thoroughly clean tough residues.
- Ideal for tank cleaning duties in the paint, chemicals, pulp and paper, and many other industries
- Optimized for cleaning tanks in harsh process environments
- Designed to recirculate fluids containing larger particles
- More robust handling of hard-to-clean residues
- Exceptional tank cleaning efficiency in industrial applications where a higher gear torque ensures durability and reliability
How does a Rotary jet head tank cleaning machine work?
Rotary jet heads use an optimized high-impact jet pattern to provide the highest possible coverage to achieve the best possible cleaning results. The flow of the cleaning fluid makes the nozzles perform a geared rotation around the vertical and horizontal axes. In the first cycle, the nozzles lay out a coarse pattern on the tank surface. Subsequent cycles gradually increase coverage until, after eight cycles, extending over the entire tank interior surface for thorough cleaning. The high jet pressure, or force of impact, efficiently removes residue to provide the cleaning conditions required for production.
"Because the jet head goes on a 360-degree rotation on two axis, it will literally wash down all the walls on the vessel and all the build-up of powder,”
Chang Chin Wai, Senior Operations Executive, GlaxoSmithKline, Singapore
Hempel A/S, Denmark
"The Alfa Laval Rotary Jet Head tank cleaning machines proved very efficient for cleaning the interior of solvent-based paint production tanks in ATEX zone environments using recovered solvent as the cleaning media."
Morten Schaarup, Project Manager, Hempel A/S, Denmark
